Inner And Outer Tea Bag Packing Machine Triangle Sachet High End

Inner And Outer Tea Bag Packing Machine Triangle Sachet High End

  • Inner And Outer Tea Bag Packing Machine Triangle Sachet High End
  • Inner And Outer Tea Bag Packing Machine Triangle Sachet High End
  • Inner And Outer Tea Bag Packing Machine Triangle Sachet High End
  • Inner And Outer Tea Bag Packing Machine Triangle Sachet High End
  • Inner And Outer Tea Bag Packing Machine Triangle Sachet High End
Inner And Outer Tea Bag Packing Machine Triangle Sachet High End
Product Details:
Place of Origin: China
Brand Name: Shilong
Certification: CE
Model Number: PHK - 201
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: L 1800 * W 900 * H 1800(mm)
Delivery Time: 15 - 25 / day
Payment Terms: D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 Set / Month
Contact Now
Detailed Product Description
Particle Content: ≤ 2 ± 0.5 G / Bag ( Other Specifications Can Be Customized ) Production Speed: Triangle Bag Inner And Outer Bag 20 - 45 Bags / Min ( Specifically According To The Material )
Tea Bag Size: Inner Bag : 58 * 60 ( 140mm ) Outer Bag : 80 * 90mm Unwinding Outer Diameter: ≤ Φ 400㎜
Inner Diameter Of Unwinding Paper Core: Φ 76㎜ Air Pressure: ≥ 0.6Mpa ( Gas Supply Guaranteed By The Customized Party )
High Light:

Heat Sealable Tea Bag Packing Machine

,

76mm Tea Bag Packing Machine

,

Triangle Tea Pouch Packing Machine



Shilong High-end Inner And Outer Tea bag Packing Machine Triangle Sachet



Product Applications:



It is suitable for inner and outer bag packing of small granular products, such as tea leaves, medicinal tea and health care tea, etc.



Product Characteristics:



1. This machine is an automatic multi-functional tea packaging equipment with a new heat sealing type. The inner and outer bag is formed at the same time, avoid your direct contact with the packing material and improve working efficiency.

2. Inner bag is made of filter paper with thread and tag attached, and outer bag is made of composite paper.

3. The biggest advantage is: tag attaching and outer bag making can adopt photoelectric positioning.

4. Packing capacity, inner bag and outer bag size can be easily adjusted according to different requirements in order to achieve the best packaging results, improve product appearance and enhance the value of the product.



Tea Bag Packing Machine Specification



Unwind quantity 1 piece
Particle content ≤ 2 ± 0.5 g / bag ( other specifications can be customized )
Packaging material requirements Inner bag: Nylon, non-woven fabric, corn fiber and other ultrasonic heat-sealable materials
Outer bag :  heat-sealable composite film
Production speed Triangle bag inner and outer bag 20-45 bags/min (specifically according to the material)
Tea bag size Inner bag : 58 * 60 (140mm) Outer bag: 80 * 90mm
Inner bag : 68 * 70 (160mm) Outer bag: 90 * 100mm
Inner bag : 80 * 80 (180mm) Outer bag: 100 * 110mm
Unwinding outer diameter ≤ Φ400㎜
Inner diameter of unwinding paper core Φ76㎜
Air pressure ≥ 0.6Mpa ( gas supply guaranteed by the customized party )
Electric power of the motor in the machine About 3.5 Kw ( 220V )
Equipment appearance About L 1800 * W 900 * H 1800 ( mm )
Equipment weight About 50kg
